Technical Data |
| Model |
SC303 |
SC303U |
SC304 |
SC304U |
SC310 |
| Power Supply |
220-240V, 50/60Hz |
110,60Hz |
220-240V,
50/60Hz |
110V,60Hz |
220-240V,
50/60Hz |
|
Motor Speed |
1250 rpm |
1500rpm |
1250 rpm |
1500 rpm |
960 rpm |
| Output Power |
250W |
120W |
150W |
120W |
150W |
| Opening Time |
7 sec |
5.5 sec |
1.8 - 2.5
sec |
1.8 sec |
1 sec |
| Max Torque |
180Nm |
36Nm |
43Nm |
| Arm Length |
5 ~ 6 m (100x44x1) |
2.5 ~ 3 m (50x2) |
2.5 ~ 3m
(75x1.5) |
| Weight |
85 Kg |
100 Kg |
| Duty Cycle |
50% |
| Working Temperature |
-25 C to 70C |
 |
|
|
|
|
|
